Timing Chains on the EZ30 - A Bit of Reality

Unlike Subaru’s 4-cyl engines that use belts, the EZ30 has timing chains that, in theory, should last the life of the engine. There’s no factory replacement interval, and many owners report them running well past 200,000–300,000 km without issue if oil changes are regular and clean.

That said, the job to replace or refresh them isn’t simple:
Chains are reliable but the tensioners and guides wear with age/mileage.
A worn tensioner can show up as a rattle, misfire, or uneven cam timing, subtle but real indicators.
The water pump is driven by the chain setup, so you might as well address it while you’re in there.
The takeaway? Don’t go into this expecting a quick belt-style swap. Expect a big teardown.



Prep Like You’re About to Open a Vault

1. Clean Every Fastener Before You Touch It

This isn’t optional. Dirt and grime in the heads of bolts means sockets don’t fit cleanly. A poor fit and slip = stripped bolts, rounds of frustration, and extra time. Good fit tools matter far more here than on simpler jobs.

This is classic advice from seasoned forum techs as they’ve lived it. You’ll save time later by spending minutes here.



2. Document Everything With Photos + Notes

When you remove the front cover, everything starts looking the same: bolts, brackets, plates. Take clear pictures as you go. Snap after every step. You don’t need a repair manual to reassemble if you have a photo diary.

This might feel tedious, until you’re trying to remember where a specific fastener came from. Owners swear by this step.



3. Label & Separate Hardware

Zip lock bags + labels are your friend. Group bolts by sub-assembly and mark them accordingly:

Chain cover bolt

Accessory brackets

Water pump hardware

Front cover bolts



Every bag should match at least one photo you’ve taken. This stops “Where did that tiny bolt go?” moments later.

Do All the Other Jobs While You’re In There

Once the timing cover is off, the engine isn’t closing itself up soon. Several owners recommend doing anything that’s harder to access once the cover is back on:

Water pump

Case Seals and O-rings

Coolant lines

Any other age-related items

These EZ30 jobs are time-consuming, and tearing down only to put it back together without refreshing ancillary parts is wasted effort.

You don’t want to pay for this teardown twice. Do it right. Owners repeatedly make the same point: it’s not that hard it’s just tedious.



Clean the Mating Surfaces

Once you’ve taken off the timing case, you now have a sealing surface. Many owners recommend that you:

Remove all old RTV and gasket material

Clean thoroughly

If possible, lightly blast the surface so new RTV has a true surface to stick to



This isn’t show-pony stuff — a poor seal here means an oil leak later. EZ30 engines aren’t known for cheap or easy oil leak fixes, so do this properly.



Tools Matter

Two tool tips saw repeated mention in forums:

Sharp, clean hex bits. Old, rounded bits will slip and strip heads.

Hammer-type impact driver. This helps on stubborn bolts that have been in place for decades.

Screw extraction kits on hand.



Cheap tools here equal frustration.



And One Last Thing It Takes Time

Forums make one point loud and clear: removing the timing cover on an EZ30 is not quick. While experienced techs might do it in a day, many who’ve DIY’d report:

Lots of bolts
Tight spaces
Slow, methodical work

Know this going in and plan your workshop time accordingly.



Final Takeaways

If you’re tackling an EZ30 timing chain job:

Prepare physically and mentally — it’s longer than you expect.

Organisation and documentation are your best tools.

While chains usually go long, tensioners and guides can age.

Do other jobs while you have access.

This isn’t a job for casual afternoons. Plan it, prep it, and work it like a major service — because it is.
